VI Forced Stirring Mixer
VI Forced Stirring Mixer
● Our introduction of absorbing foreign technology, developed VI Forced Stirring Mixer. ● ...
Detailed description
Overview:
● Our introduction of absorbing foreign technology, developed VI Forced Stirring Mixer.
● The machine of fine powder, or two or more clots after the powder body, the material can contain some water mix. Such as micro-phase and additives can be mixed to achieve the effect (that adds a very small number of ingredients mixed).
Technical parameters:
| Model | Production capacity (kg/time) | Total volume (m3) | Mixing time (min) | Power(kw) | Speed of bucket (r/min) | Stirring speed (r/min) | Dimensions(mm) | Weight(kg) |
| V1-180 | 60 | 0.18 | 2-5 | 1.1×2 | 12 | 500 | 1730×700×1580 | 320 |
| V1-300 | 80 | 0.3 | 4-10 | 1.1×2.2 | 12 | 500 | 2005×700×1760 | 360 |
| V1-500 | 130 | 0.5 | 4-10 | 1.1×2.2 | 12 | 500 | 2660×1250×2400 | 600 |
| V1-1000 | 240 | 1 | 6-10 | 3×2.2 | 12 | 500 | 3220×1500×2840 | 1000 |
